Specification - CF30 Series |
|
|
Models |
CF30000-RGB丨CF33000-RGB |
|
Source | Type: |
Semiconductor diode | Full-colour RGB laser projector |
|
Suitability: |
indoor laser displays [atmospheric, abstract, text, animations] |
|
Beam Size@Aperture[mm] |
6.5*7mm |
|
Divergence（full angle） |
1.0mrad |
|
System control |
Auto, SD card, DMX, RJ45, Interlock, ILDA ( optional FB4) |
|
Scanning System |
OPT-50B:40Kpps@8° ，60°MAX (measured data) |
|
Wavelength [nm] |
30W:R/638 G/525 B/445nm+465nm(2*450&1*465nm） |
|
Laser Power [mW] |
30W:8500mW / 10000mW / 12500mW |
|
Guaranteed opt. output [mW] |
31W丨33.5W |
|
Modulation [kHz] |
100 | analogue |
|
Power Supply |
100~240V 50~60Hz |
|
Power Consumption [W] |
380W |
|
Weight [kg] |
14.6Kg |
|
Size [WxHxD, mm] |
L375.8*W391.8*H354.5mm |
|
Cooling: |
Heatsink+TEC Cooling+Casting Aluminum Housing+Fans (at bottom) |
|
Packaging: |
Road case |
|
Operation temperature [°C]: |
minus 20℃ to 40℃ |
