CF20 Series 20W RGB Laser Module
RGB-20W
Over the years, we extensively expanded our range of laser modules, and now we cover a broad spectrum of laser wavelengths. From ultraviolet lasers, via the visible spectrum, up to near-infrared lasers.
Currently, we offer Thousands of different laser modules, with power output ranging from 5mW up to 180 Watts, in the range from 405nm to 660nm.Our mission is to ensure that a uniform and quality beam comes out of every Optlaser laser module. Single-diode lasers, multi-diode assemblies as well as solid-state lasers can be combined into a single free space beam or fiber-coupled output.
Currently, we offer Thousands of different laser modules, with power output ranging from 5mW up to 180 Watts, in the range from 405nm to 660nm.Our mission is to ensure that a uniform and quality beam comes out of every Optlaser laser module. Single-diode lasers, multi-diode assemblies as well as solid-state lasers can be combined into a single free space beam or fiber-coupled output.
Quantity
OPT-RGB-20W RGB Laser Module
Optlaser CF20 Series 20W RGB Laser Module is lightweight, convenient, easy to integrate.
CF20 Series 20W RGB Laser Module has good light beam quality, stable performance, and high modulation efficiency. The 20W RGB Laser Module with Digital Driver Power Supply, it's widely used in stage lighting, laser projection, outdoor lighting, laser positioning, laser communication, spectrum analysis, etc. Please check the data sheet of 20W RGB Laser Module as below:
Wavelength range (nm) | 638±5 | 525±5 | 465±5 | |
Output power (W) | 5.6 | 6 | 8.5 | |
Light Beam type | All-fiber shaping | |||
Power stability (rms, over 4 hours) | <1 | |||
Working mode | CW | |||
LightBeam at exit (1/e2, mm) | 5*7 | |||
LightBeam at 10 meters (1/e2, mm) | 18*20 | |||
LightBeam at 20 meters (1/e2, mm) | 30*28 | |||
Beam divergence (mrad) | 1.1 | |||
Warm-up time (minutes) | <1minutes | |||
Light height (mm) | 40 | |||
Working temperature (℃) | -30℃~40℃ | |||
Power supply | DC 24V | LMF350-23B24UH | ||
Analog modulation (0~5V) | >2V full power light, <2V shut off light | ≈0.12V~4.95V | ||
Expected life (hours) | 10000 | |||
Warranty time | 1-year | |||
Please contact with Optlaser Team to get the details of Optlaser Professional 20W RGB Laser Module RGB Laser Module with Digital Driver Power Supply!
