CF20 Series 32W RGB Laser Module
RGB-32W
Over the years, we extensively expanded our range of laser modules, and now we cover a broad spectrum of laser wavelengths. From ultraviolet lasers, via the visible spectrum, up to near-infrared lasers.
Currently, we offer Thousands of different laser modules, with power output ranging from 5mW up to 180 Watts, in the range from 405nm to 660nm.Our mission is to ensure that a uniform and quality beam comes out of every Optlaser laser module. Single-diode lasers, multi-diode assemblies as well as solid-state lasers can be combined into a single free space beam or fiber-coupled output.
Currently, we offer Thousands of different laser modules, with power output ranging from 5mW up to 180 Watts, in the range from 405nm to 660nm.Our mission is to ensure that a uniform and quality beam comes out of every Optlaser laser module. Single-diode lasers, multi-diode assemblies as well as solid-state lasers can be combined into a single free space beam or fiber-coupled output.
Quantity
OPT-RGB-32W RGB Laser Module
- 32W RGB Color Changing: Offers vibrant colors and smooth transitions for dynamic stage effects.
- External Dimming Control: Adjust brightness effortlessly for perfect lighting ambiance.
- High-Quality Pure Diodes: Ensures long-lasting performance and optimal light output.
- Beam Angle Customization: Adjusts beam spread for various stage setups.
- Stage Lighting Solution: Ideal for enhancing performances with professional-grade lighting.
- Digital Driver Technology: Delivers superb dimming linearity and accurate color mixing (Cyan, Yellow, Orange, Purple, Magenta) for consistent, vivid outputs.
Wavelength range (nm) | 638±5 | 525±5 | 465±5 | |
Output power (W) | 9 | 10 | 813 | |
Light Beam type | All-fiber shaping | |||
Power stability (rms, over 4 hours) | <1 | |||
Working mode | CW | |||
LightBeam at exit (1/e2, mm) | 5*7 | |||
LightBeam at 10 meters (1/e2, mm) | 18*20 | |||
LightBeam at 20 meters (1/e2, mm) | 30*28 | |||
Beam divergence (mrad) | 1.1 | |||
Warm-up time (minutes) | <1minutes | |||
Light height (mm) | 40 | |||
Working temperature (℃) | -30℃~40℃ | |||
Power supply | DC 24V | LMF350-23B24UH | ||
Analog modulation (0~5V) | >2V full power light, <2V shut off light | ≈0.12V~4.95V | ||
Expected life (hours) | 10000 | |||
Warranty time | 1-year | |||
