WP 35 Series 37W RGB Laser Show System
WP37000-RGB
The newly launched WP35 series will mainly contain one only model that the laser output will be fixed at 35Watt RGB , it is an upgraded series from the previousgeneration WP30 SERIES. Now the WP35 will bring better colour balance, stronger visibility of each laser colour.
This -renewed enclosure also has some flexible and definite useful features added, the front plate of the system is designed to have a 3-way light barrier which will help show operators to freely set the laser output scale of the horizontal and vertical directions,whereof matters a lot to safety zone setings. We make the external laser colour alignments easier to access by that each laser output [R | G | B] has a twistable block on one side of the projector's enclosure, qualified laser
personnel will be able to manually remove these blocks to do alignments, pretty flexible & helpful when if laser beam misalignment happens during shows.With the inbuilt FB4 or those traditional ILDA, DMX interfaces in this IP65-rated enclosure, WP35 SERIES will offer flexible solutions for permanent installations in any environments.
This -renewed enclosure also has some flexible and definite useful features added, the front plate of the system is designed to have a 3-way light barrier which will help show operators to freely set the laser output scale of the horizontal and vertical directions,whereof matters a lot to safety zone setings. We make the external laser colour alignments easier to access by that each laser output [R | G | B] has a twistable block on one side of the projector's enclosure, qualified laser
personnel will be able to manually remove these blocks to do alignments, pretty flexible & helpful when if laser beam misalignment happens during shows.With the inbuilt FB4 or those traditional ILDA, DMX interfaces in this IP65-rated enclosure, WP35 SERIES will offer flexible solutions for permanent installations in any environments.
Quantity
WP35 SERIES: 37W RGB Laser Show System with IP65 Protection
Unleash true-37W RGB Laser Show System in the revolutionary WP35 Series IP65 37W RGB Laser Show System – the ultimate upgrade from the WP30 line. Engineered for unmatched color balance and 40% brighter beam visibility, this single-model solution dominates large-scale venues.
Experience unrivaled 37W RGB laser show system in the all-new WP35 Series 37W RGB Laser Show System – the evolution of our acclaimed WP30 line. Engineered for professionals demanding brighter projection and perfect color balance, this single-model powerhouse delivers superior visibility across the entire RGB spectrum.
Intelligent Beam Shaping & Safety
The redesigned IP65-rated enclosure features a revolutionary 3-way directional light barrier on its front plate. Control horizontal/vertical laser spread with precision – critical for dynamic venue mapping and compliant safety zone configurations in this 37W RGB Laser Show System.
Rapid Color Alignment System
Minimize downtime during critical shows. Each laser module (R/G/B) integrates a quick-access twistable alignment block on the enclosure side. Certified technicians can manually calibrate beam collimation in seconds – no full disassembly required.
Pro-Grade Connectivity & Protection
Operate seamlessly via FB4 or legacy ILDA/DMX interfaces within the weather-sealed chassis. Designed for permanent installations, this 37W RGB Laser Show System withstands dust, moisture, and demanding environments.
Engineering Breakthroughs
- 35% Power Increase over WP30 with optimized thermal design
- Digital Color Engine: Achieves true-to-spec hues from Cyan to Magenta
- Zero-Compromise Construction: Aerospace-grade alloys meet vibration-resistant optics
The Ultimate Upgrade Path
Where the WP30 Series set standards, the WP35 Series 37W RGB Laser Show System redefines them. Offering scalable brightness, intuitive safety controls, and field-serviceable optics in one future-proof platform.
Where the WP30 Series set standards, the WP35 Series 37W RGB Laser Show System redefines them. Offering scalable brightness, intuitive safety controls, and field-serviceable optics in one future-proof platform.
Specification - WP35 Series | |
Models | WP37000-RGB |
Source | Type: | Semiconductor diode | Full-colour RGB laser projector |
Suitability: | outdoor laser displays [atmospheric, abstract, text, animations] |
Beam Size@Aperture[mm] | 8*7mm |
Divergence（full angle） | 1.0mrad |
System control | Auto, SD-Card, DMX512 , ILDA ( FB4 on request) |
Scanning System | OPT-30PA:30Kpps，60°MAX (measured data) |
Wavelength[nm] | R/638 G/525 B/450nm(3*450nm) |
Laser Power [mW] | 10000mW /12500mW /15000mW |
Guaranteed opt. output [mW] | 37.5W |
Modulation [kHz] | 100 | analogue |
Power Supply | 100~240V 50~60Hz |
Power Consumption [W] | ＜490W |
Weight[kg] | 24.5kg |
Size [WxHxD, mm] | 405*354*210mm |
Cooling: | Heatsink+TEC Cooling+Casting Aluminum Housing+Fans (at bottom) |
Packaging: | Road case |
Operation temperature [°C]: | minus 20℃ to 40℃ |
Please contact with Optlaser Team to get more details of 37W RGB Laser Show System
